ALLNET VDSL2 ALL-MC115 & MC116-Serie zbh. HUT-Schienenadapter/DIN-Rail-Adapter

Hightlights: VDSL2 modem optionally adjustable as master or slave Simple 2-wire connection for point-to-point connection Up to 160 Mbit/s symmetrical for up to 3km (cable dependent) 2x RJ45 10/100/100Mbps Ethernet ports NEW: 1x 1000Base-X SFP slot for optional SFP modules also available as practical bundle of 2 Optional DIN-Rail Adapter: Art. 102424 Supports jumbo frames (2K bytes MTU) Selectable G. INP mode Selectable 8-band profile With the ALL-MC116VDSL2 modem ALLNET introduces a pure VDSL2 single port bridge to the market, which fulfills the basic requirement of a perfomant point to point connection via 2 wire connection - typically a telephone connection - with all advantages of a VDSL2 connection. The modem has RJ11 jacks as well as terminal jacks for the pure wire connection. The additional possibility to ground the devices (with the ALL95100 lightning protection) brings the necessary protection against lightning strikes in the application area. Two Gigabit ports connect the modem to the network. In the new ALL-MC116VDSL2 is now also an optional Gigabit SFP slot available to expand the communication with copper or Fibre GBIC modules if necessary. The ALL-MC116VDSL2 can be configured quickly and easily as either a master or slave modem via the DIP switch. On the front of the device there are numerous LEDs for visual signaling of the operating states and connections. Technical Details: Element Spezifikation Standards: IEEE 802.3ab IEEE802.3u IEEE 802.3z Interface: 2x 10/100/100Base-T RJ45 1x 1000Base-X SFP Slot VDSL Interface:   Connector: RJ-11/Terminal block DMT Encoding/PTM Transmission On-board surge protector MTU: 2K 4-position DIP Switch   Selectable CO or CPE mode Selectable Band profile Selectable G.INP   Power supply: DC 12V via AC switching adapter (including) Power Consumption: 3W Typical LED-Indicators: LAN: Act/Link, PWR: Power Line: Act/Link, Line Mode: CO/CPE   Housing: Metal housing Dimensions: 124 x 93 x 27 mm (4.88" x 3.66" x 1.06") Weight:   Approximately 0.34Kg only the device Environment: 0~50° C (Operating Temperature) -20~70° C (Storage Temperature) 10 - 90% (non-condensing Humidity) Marks: CE, FCC, RoHS Compliant Package contents: 1x ALL-MC116VDLS2 modem 1x external power supply 1x manual

Hightlights: Cost-effective VDSL2/fiber/Ethernet unmanaged bridge modem Supports VDSL profiles 8a, 8b, 8c, 8d, 12a, 12b, 17a Supports 1000Base-X SFP slot Supports ITU-T G.993.5 vectoring Supports G. INP Supports UPBO & DPBO Supports compact size and DIN rail mounting (optional bracket see accessories) Supports Jumbo Frame (MTU) 2K bytes on VDSL side The ALL-MC116SV-VDLS2 is a cost-effective unmanaged VDSL2 bridge modem. It uses the G.993.2 VDSL2 standard technology for data transmission on only one copper cable pair. Data transmission over only a single copper cable pair. The ALL-MC116SV-VDSL2 is specifically designed to support vectoring for Telcom & ISP to Hospitality solutions for operation on DSLAM's. The modem is therefore compatible with standard VDSL up to 100Mbit VDSL connections. The modem has 2x 10/100/1000Base-T Ethernet ports and an additional 1000Base-X SFP slot offers this extender a flexible solution to extend the LAN network and is perfect for use in buildings, hotels, hospitals or other locations outside the range of 10/100/1000Base-T (Ethernet) or fiber. Especially the vectoring technology distinguishes the ALL-MC116SV-VDSL2 from its brothers that it is designed for vectoring connection to a DSLAM, no matter if it is used for provider ISP or in-house DSLAM later. Important to note it is an unmanaged device. With unmanaged bridge modem you have NO chance to read out the bandwidth or to set VLAN tags etc. Technical Details: Element Spezifikation Standards: IEEE 802.3ab IEEE802.3u IEEE 802.3z Interface: 2x 10/100/100Base-T RJ45 1x 1000Base-X SFP Slot VDSL2 Interface:   Comply with ITUT G993.2 Connector: RJ-11/Terminal block DMT Encoding/PTM Transmission On-board surge protector MTU: 2K Power supply: DC 12V via AC switching adapter (including) Power Consumption: 3W Typical LED-Indicators: LAN E1/E2: Act/Link, SFP port: Link Line: Act/Link, System: PWR   Housing: Metal housing Dimensions: 124 x 93 x 27 mm (4.88" x 3.66" x 1.06") Weight:   Approximately 0.34Kg only the device Environment: 0~50° C (Operating Temperature) -20~70° C (Storage Temperature) 10 - 90% (non-condensing Humidity) Marks: CE, FCC, RoHS Compliant Package contents: 1x ALL-MC116SVDLS2 modem 1x external power supply 1x manual

Hightlights: Cost-effective VDSL2 Ethernet unmanaged bridge modem Supports VDSL profiles 8a, 8b, 8c, 8d, 12a, 12b, 17a Supports 1000Base-X SFP slot Supports ITU-T G.993.5 vectoring Supports G. INP Supports UPBO & DPBO Supports compact size and DIN rail mounting (optional bracket see accessories) 2x Gigabit ports with PoE according to IEEE802.3at max. 30W per port. = Budget 60W Supplied PoE power supply which according to medical certification IEC/EN/UL60601-1 1x MOPP The ALL-MC116SPV-VDLS2 is a cost-effective unmanaged VDSL2 bridge modem with integrated 2x port PoE switch according to IEEE802.3at with max. 30W per PoE port. It uses the G.993.2 VDSL2 standard technology for data transmission on only one copper cable pair. Data transmission over only a single copper cable pair. The ALL-MC116SPV-VDSL2 is specifically designed to support vectoring for Telcom & ISP to hospitality solutions for operation on DSLAM's. The modem is therefore compatible with standard VDSL2 up to 100Mbit VDSL2 connections. The modem has 2x 10/100/1000Base-T Ethernet ports with PoE IEEE802.3at max. 30W per port. PoE budget = 60W. Thus, this extender offers a flexible solution to extend the LAN network and is perfect for use in buildings, hotels, hospitals or other places outside the range of 10/100/1000Base-T (Ethernet). Especially the vectoring technology distinguishes the ALL-MC116SPV-VDSL2 from its brothers that it is designed for vectoring connection to a DSLAM, whether it is used for provider ISP or in-house DSLAM later. Important to note, this is an unmanaged device. With unmanaged bridge modems you have NO chance to read out the bandwidth or set VLAN tags etc.. Of course you can read out the data at your DSLAM as they synronized. The 2x PoE ports according to IEEE802.3at with max. 30W per port are now still ideal to operate PoE devices such as WLAN access points or PoE tablets up to patient monitors or other end devices in the hospital room/hotel room/nursing homes etc. directly on the two ports. Medicine power supply according to IEC60601-1 1x MOPP. Technical Details: Element Spezifikation Standards: IEEE 802.3ab IEEE802.3u IEEE 802.3z Interface: 2x 10/100/100Base-T RJ45 mit IEEE802.3at PoE Port mit max. 30W pro Port = 60W PoE Budget VDSL2 Interface:   Comply with ITUT G993.2 VECTORING Connector: RJ-11/Terminal block DMT Encoding/PTM Transmission On-board surge protector Power supply: DC 54V AC to DC Medial compliant IEC/EN/UL60601-1 1x MOPP switching adapter (including) Power Output: 60W Maximum (each LAN port 30W) LED-Indicators: AN:Act/Link,   PoE,   Overload VDSL2:  Act/Link,  Line  Mode:  CO/CPE Housing: Metal housing Dimensions: 137 x 100 x 27 mm (5.39" x 3.94" x 1.06") Weight:   Approximately 0.42Kg only the device Environment: 0~50° C (Operating Temperature) -20~70° C (Storage Temperature) 10 - 90% (non-condensing Humidity) Marks: CE, FCC, RoHS Compliant Package contents: 1x ALL-MC116SPVDLS2 modem 1x external medial compliant IEC/EN/UL60601-1 1x MOPP power supply 1x manual

H507xB654xT488mm, Lichtgrau ähnlich RAL7035, Vollblechtüre mit 2xSchloss und Eintrittsluftfilter, 4xLochrasterprofile 19" (vorder/Rückseite), Profilabstand zwischen der vorderen und hinteren 19" 300mm(max. Veränderbare auf Nutztiefe 350mm), Öffnungen für Kabeleingang unten(8x 40mm), Stahlblechgehäuse, incl. 2-Fach Lüftereinheit 2x Lüfter mit Thermostat, Schalter, 220V/0,32A, mit 1m Netzanschlusskabel, Lichtgrau RAL7035, Lüftergeräuschpegel ca.45dB, IP55 Geschützt gegen Staub in schädigender Menge, Schutz gegen Spritzwasser

Lichtgrau ähnlich RAL7035, T150/B483/H133mm, wird an der 19" Ebenen befestigt B465mm Befestigungslochabstand, Nutztiefe 140mm, Din-Railschiene T6mm zur aufnahme von Industrieswitchen und anderen Dinrail Geräten,

Lichtgrau ähnlich RAL7035, T150/B483/H222mm, wird an der 19" Ebenen befestigt B465mm Befestigungslochabstand, Din-Railschiene T6mm zur aufnahme von Industrieswitchen und anderen Dinrail Geräten,

H322xB450xT223mm, Lichtgrau ähnlich RAL7035, Vollblechtüre mit Schloss, Montageplatte mit 1xDIN-Rail Schiene L=350mm, 3x Runde Öffnungen für Kabeleingang unten(1xD20/2xD15mm), verzinktes Stahlblechgehäuse(SGCC-Stahl), Nutztiefe 140mm,
