Ubiquiti UniFi SuperLink • UniFi Protect Sensor Gateway • Bluetooth • PoE • UP-SuperLink

A battery-powered smart sensor capable of detecting motion, lighting, and environmental changes. Motion detections up to 5 m (16 ft) Temperature and humidity sensing Ambient light sensing Alarm sound sensing* Door and window state sensing Up to 1 year of battery life Connects to UniFi Bluetooth-enabled access point** *Based on UL217 and UL2034 alarm patterns. **Must be connected to an up-to-date Bluetooth-supported UniFi Access Point.   Technical Specifications Mechanical Dimensions Ø24 x 83.5 mm (Ø0.94 x 3.29") Weight 50.2 g  (1.77 oz) Enclosure material Polycarbonate Mount materials Flat wall mount: polycarbonate, adhesive Corner mount: polycarbonate, adhesive Additional gear Magnet Water sensor adapter (Only available in the 3-pack.) Hardware Networking interface Bluetooth 5.0, BLE Max. TX power 5 dBm Max. power consumption 77mW Power method Lithium battery CR123A Sensor features Motion sensor (5 m/16 ft max. range) Magnetic entry sensor for door or window open/close Accelerometer for garage door open/close Temperature sensor Humidity sensor Ambient light sensor Alarm sound sensor Water sensor for detecting leaks and floods (requires water sensor adapter accessory, only available in 3-pack at general release) BLE connectivity from access point in indoor setting (recommended range 15 m/49 ft, performance will vary based on environment) Antenna 2.4GHz Antenna gain 0.5 dBi LEDs R/B/W Button Factory reset Operating temperature 0 to 45° C (32 to 113° F) Operating humidity 10 to 90% noncondensing Certifications FCC, IC, CE Software Web application UniFi Protect Mobile app UniFi Protect iOS™ and Android™

A battery-powered smart sensor capable of detecting motion, lighting, and environmental changes. Motion detections up to 5 m (16 ft) Temperature and humidity sensing Ambient light sensing Alarm sound sensing* Door and window state sensing Up to 1 year of battery life Connects to UniFi Bluetooth-enabled access point** *Based on UL217 and UL2034 alarm patterns. **Must be connected to an up-to-date Bluetooth-supported UniFi Access Point.       Technical Specifications Mechanical Dimensions Ø24 x 83.5 mm (Ø0.94 x 3.29") Weight 50.2 g  (1.77 oz) Enclosure material Polycarbonate Mount materials Flat wall mount: polycarbonate, adhesive Corner mount: polycarbonate, adhesive Additional gear Magnet Water sensor adapter (Only available in the 3-pack.) Hardware Networking interface Bluetooth 5.0, BLE Max. TX power 5 dBm Max. power consumption 77mW Power method Lithium battery CR123A Sensor features Motion sensor (5 m/16 ft max. range) Magnetic entry sensor for door or window open/close Accelerometer for garage door open/close Temperature sensor Humidity sensor Ambient light sensor Alarm sound sensor Water sensor for detecting leaks and floods (requires water sensor adapter accessory, only available in 3-pack at general release) BLE connectivity from access point in indoor setting (recommended range 15 m/49 ft, performance will vary based on environment) Antenna 2.4GHz Antenna gain 0.5 dBi LEDs R/B/W Button Factory reset Operating temperature 0 to 45° C (32 to 113° F) Operating humidity 10 to 90% noncondensing Certifications FCC, IC, CE Software Web application UniFi Protect Mobile app UniFi Protect iOS™ and Android™
